Trotec TTV3000 Fan
Single speed 3000 m3/h axial fan/ventilator for confined space air movement or general medium to high volume air movement.
The Trotec TTV3000 is an axial fan/ventilator designed for confined space ventilation and general air movement in small to medium environments. It has a single speed operation of 3000 m3/h airflow.
With a pressure of 300 PA, the TTV3000 has the ability to push air further than a standard axial fan.
Whether used for the fresh air supply in poorly ventilated areas or for ventilation during channel construction or welding jobs, wherever large amounts of air have to be circulated moderately, quickly and easily in not too harsh circumstances, the axial fans of the TTV series are in their element.
Just set it up, switch it on, all is done.
Optional 305mm flexible 7.6m hoses can be attached to the TTV3000 to distribute the air into confined spaces or to further away locations. A washable 3m dust bag can also be attached to the rear of the fan and filters dust and dirt particles reliably out of the air.
The Trotec TTV3000 comes standard with a 1 Year Manufacturer's warranty covering any defects in materials or workmanship
Specifications
- Airflow Rate: 3000 m3/hour
- Stages: Single speed
- Air Pressure: 300 Pa
- Hose/Ducting Size: 305mm diameter, 7.6m length
- Dust Bag Size: 3m length
- Power Consumption: 0.44kW
- Noise Level: 79 dB (A)
- Dimensions: 470mm x 460mm x 390mm
- Weight: 17kg
Packages
Product | Details | Price |
---|---|---|
Trotec TTV3000 Fan | TTV3000, 230V NZ/AUS power lead, user manual |
SOLD OUT - CALL 0800 500 380 TO ENQUIRE
|
Trotec SPT305 Ventilation Ducting 7.6m | Ventilation/temperature grade flexible ducting with reinforced steel spirals for added strength with a maximum temperature of up to 100°C. |
|
Trotec Hose Lashing Strap | Adjustable connecting strap with an automatic stop mechanism at the strap buckle used to connect the ducting to the TTV ventilators. |
|
Trotec 305mm Hose Joiner | Aluminium hose joiner 305mm used for connecting multiple lengths of SPT ducting to the TTV3000. |
